Ecumaster PMU-16 - Page 55

4
o9.status,
o9.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
o10.status,
o10.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
5
o11.status,
o11.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
o12.status,
o12.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
6
o13.status,
o13.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
o14.status,
o14.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
7
o15.status,
o15.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
o16.status,
o16.active
3 bits
1 bits
Unsigned
0-7
0-1
- 0 -
ID BaseID + 2 Frequency: 62.5Hz
ByteID Channel Data Width Data Type Range Resolution Offset Unit
0 a1.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
1 a2.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
2 a3.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
3 a4.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
4 a5.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
5 a6.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
6 a7.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
7 a8.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
ID BaseID + 3 Frequency: 62.5Hz
ByteID Channel Data Width Data Type Range Resolution Offset Unit
0 a9.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
1 a10.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
2 a11.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
3 a12.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
4 a13.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
5 a14.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
6 a15.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
7 a16.voltage 8 bits Unsigned 0-5 0.0196V/bit 0 V
Page 55
