ID BaseID + 4 Frequency: 62.5Hz
ByteID Channel Data Width Data Type Range Resolution Offset Unit
0 o1.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
1 o2.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
2 o3.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
3 o4.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
4 o5.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
5 o6.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
6 o7.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
7 o8.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
ID BaseID + 5 Frequency: 62.5Hz
ByteID Channel Data Width Data Type Range Resolution Offset Unit
0 o9.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
1 o10.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
2 o11.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
3 o12.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
4 o13.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
5 o14.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
6 o15.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
7 o16.current 8 bits Unsigned 0-63.75 0.25A/bit 0 A
ID BaseID + 6 Frequency: 62.5Hz
ByteID Channel Data Width Data Type Range Resolution Offset Unit
0 o1.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
1 o2.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
2 o3.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
3 o4.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
4 o5.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
5 o6.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
6 o7.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
7 o8.voltage 8 bits Unsigned 0-16.19 0.063V/bit 0 V
