5 Configuring System
ED-HMI2120-101C User Manual 5-3
the current device IP.
Preparation:
ED-HMI2120-101C has been connected to the network through the router.
The IP and network password of the router in the network have been obtained, and the IP
address is 192.168.X.X.
Steps:
1. Open a browser, Enter the router IP of the network where ED-HMI2120-101C is located in
the address bar: 192.168.x.x, and press Enter to enter the router login interface.
2. According to the interface prompts, enter the network password and enter the router
management interface.
3. Find the IP address of ED-HMI2120-101C in the terminal device of the management
interface.
5.1.3 Scan For Using NMAP Tool
When the device starts normally but the display is not connected, you can use nmap tool to scan the
IP under the current network to obtain the IP information of the device. Nmap supports Linux, macOS,
Windows and other platforms.
Preparation:
ED-HMI2120-101C has been connected to the network through the router.
The IP segment and mask of the router in the network have been obtained, for example,
192.168.X.X/24, where 24 is the subnet mask.
Steps:
For example, using nmap to scan the network segments from 192.168.3.0 to 255, you can use the
following steps:
1. Open the nmap tool and scan the hosts in the 192.168.X.X/24 network segment.
NOTE:
The nmap tool operates differently in different operating systems, so please follow the actual interface or
command prompts.
