EDA ED-HMI2120-101C - Remote Login; Connecting to the Device Via SSH

5 Configuring System
ED-HMI2120-101C User Manual 5-5
5.2 Remote Login
There are many remote login methods, and users can choose according to their actual needs. This
chapter only introduces SSH and VNC.
5.2.1 Connecting To The Device Via SSH
If the device uses Lite system, you can choose to connect to the device remotely through SSH to
configure or debug it.
The tools for remote login are selected by users themselves, and the following is an example of logging
in through MobaXterm.
Preparation:
 The MobaXterm tool has been installed on the PC.
 ED-HMI2120-101C has been connected to the network through the router.
 IP address of ED-HMI2120-101C has been get.
Steps:
1. Open MobaXterm, click , and open the window for creating connection, as shown in the
figure below.
2. Click in the upper left corner to open the SSH connection interface.
