H100B Pulse Oximeter User Manual
- 32 -
Figure 3-2 Model
If the POST is successfully finished, the
oximeter sounds a tone and enters the main
interface.
If there is an error during the POST, the following error
codes will display on the screen:
Error code Indication
Error 01 Indicates error for low battery
Error 02 Indicates error for SpO
2
board
Error 03 Indicates error for main control board
3.2 Measurement State
3.2.1 Measurement Modes
There are two measurement modes which are waveform
mode and large numeric mode. By default, the
configuration is waveform mode.
Waveform Mode
In the normal measurement state, oximeter can measure
