SEASTAR and BAYSTAR Hydraulic Steering Systems
10-9
HF5518 Vertical Bleeder Tee
HF5521 Vertical Bleeder Tee
HF5520 Horiz. Bleeder Tee HF5519 Bleed Tee (TM Cylinders)
HF5529 Elbow Fitting
HF5528 Straight Fitting HF5527 Union Coupling Fitting
HF5526 Tube Nut
(6 per kit) For use with 3/8"
Nylon and/or 3/8" copper
tubing
(3 per kit) (3 per kit)
HF5530 Tee FittingHF5533 Tee Fitting
HF5532 Connector Fitting
HF5531 Tee Fitting
(3 per kit)(3 per kit)
(3 per kit)
(3 per kit)
HF5534 Elbow Fitting HF5538 Street Elbow
HF5536 Tee Fitting HF5524 Cap Plug Nut
(3 per kit)
(3 per kit)(3 per kit)
(3 per kit)
(2 per kit inc.'O' Ring)
For use with Front Mount
Cylinders ONLY
3/8" TUBE
3/8" TUBE
1/4" NPT
3/8" TUBE
(3 per kit)
1/4" NPT
3/8" TUBE
3/8" TUBE
3/8" TUBE
1/4" NPT
3/8" TUBE
3/8" TUBE
1/4" NPT
1/4" NPT
All SeaStar Manual Hydraulic
steering systems utilize
the same style of fittings
for all applications. These
are 3/8" compression
fittings which utilize a
9/16"–24 extra fine thread.
Refer to page 10-1.
3/8" TUBE
3/8" TUBE
1/4" NPT
3/8" NPT
3/8" TUBE
3/8" TUBE
3/8" TUBE
HF5540 45° Fitting
(2 per kit)
1/4"
NPT
3/8" TUBE
3/8" TUBE
3/8" TUBE
3/8" NPT
3/8" TUBE
HF5548 Bleed Nipple
FITTINGS
1/4" NPT
1/4" NPT
3/8" TUBE
BLEED NIPPLE
BLEED NIPPLE
3/8" NPT
3/4" UNF
3/8" TUBE
BLEED NIPPLE
3/8" TUBE
BLEED NIPPLE
3/8" NPT
(2 per kit)
(2 per kit) (2 per kit)
(2 per kit)
45˚ FLARE
(2 per kit)
HF5566 Adapter Fitting
3/8" TUBE
9/16"–18UNF
JIC 37.5
FLARE
FITTINGS
