SEASTAR and BAYSTAR Hydraulic Steering Systems
10-13
FITTING KITS
2 OF EACH ILLUSTRATED INCLUDED IN KIT
2 OF EACH ILLUSTRATED INCLUDED IN KIT
HF5512
3/4" bulkhead fitting kit
Application: Single cylinder
installations
2 Assemblies per kit
ITEM
QUANTITY PART
NO. DESCRIPTION PER KIT NO.
1 Connector Fitting 2 286323
2 Street Elbow 2 600606
3/8" Tube (M) –
1/4" NPT(F)
3 Washer 4 202224
4 Nut 4 191621
HF5513
3" bulkhead fitting kit
Application: Single cylinder
installations
2 Assemblies per kit
ITEM
QUANTITY PART
NO. DESCRIPTION PER KIT NO.
1 Connector Fitting 2 600608
2 Street Elbow 2 600606
3/8" Tube (M) –
1/4" NPT(F)
3 Washer 4 202224
4 Nut 4 191621
