Edimax CV-7428nS User Manual

25
different kinds of data, to give higher
priority to applications which require instant
responses. This improves the performance
of such network applications.
IPTV Multicast
to Unicast
Enable internet TV multicast packet to
unicast.
Multicast Data
Rate
When you disable IPTV multicast to unicast,
you can set the data rate of the multicast
packet here.
TX Power
You can set the output power of the
wireless radio. Unless you’re using the
wireless bridge in a very large space, you
may not require 100% output power. This
will enhance security (malicious/unknown
users in distant areas will not be able to
reach your wireless bridge).
Enable LED Off
Mode
Check this box to enable “LED Off Mode”
which allows you to turn off all LEDs, or all
LEDs except the power LED. After checking
the box, select “Turn off all LED indicators”
or “Turn off all LED indicators except the
power LED” according to your preference.
Click “APPLY” to make changes take effect. The following message will appear:
Click “CONTINUE” to save the changes but not apply them yet. This allows you
to make further changes in the browser based configuration interface, before
applying them all at once.
Click “APPLY” to restart the device and implement any changes. The device will
restart itself.

Edimax CV-7428nS Specifications

Power

power adapter voltage	DC 5V
power adapter current	1A

Operating Environment

humidity	10-90% (Non-condensing)
temperature range	0-40°C
temperature range in Fahrenheit	32 - 104°F

Wireless Standards

frequency band	2.4 GHz
IEEE 802.11n data rate	up to 300Mbps
IEEE 802.11g data rate	up to 54Mbps
IEEE 802.11b data rate	up to 11Mbps

Ports & Interfaces

LAN ports	5 x RJ-45
antenna type	2 x 2dBi external antennas
LED indicators	Power, Wireless, LAN ports

Weight and Dimensions

weight	155 grams
height	30 mm
width	127 mm
depth	96 mm
