Edimax EW-7416APn v2 User Manual

17
II-2-2. AP Client Mode
1. Select AP Client Mode and click “Next”.
2. You will have the option to
change the password used to
access the device’s configuration
settings. For first time setup,
please simply click “Next”
without changing anything.
3. The device will search for nearby wireless networks to connect to. If you
cannot find the access point you
wish to connect to, click “Scan” to
refresh the list of wireless networks.
Select the wireless network you wish
to connect to, and click “Next” to
continue.
4. If the wireless network you selected
requires a network security key,
enter it here. If you do not know the
network security key then please
refer to Appendix “How to Find Your
Network Security Key” for guidance.
Click “Next” to continue when
finished.
5. You will see a final confirmation
screen, listing the settings you have
selected. If everything is correct,
click “Set” to continue.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
