Edimax EW-7416APn v2 User Manual

25
III-1. Home
The Home page displays 11 categories in the left panel which you can select:
- III-1. Home
- III-2. Basic Settings
- III-3. WPS Setting
- III-4. Advanced Settings
- III-5. Security
- III-6. Radius Server
- III-7. MAC Filtering
- III-8. System Utility
- III-9. Configuration Tool
- III-10. Upgrade
- III-11. Reset
At the top of the screen on the right side there is a drop
down menu to change the language of the browser based
configuration interface.
The “Status and Information” screen is displayed in the
main window. This shows basic system information about the access point for
reference, such as firmware version, wireless mode and SSID, and the access
point’s IP and MAC address.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
