Edimax EW-7416APn v2 User Manual

26
System
Uptime
Displays the total time the access point has been
operational since it was last switched on.
Hardware Version
Displays hardware version. This information is helpful
if you experience problems with your access point
and need technical support.
Runtime Code Version
Displays current firmware version. This information is
useful when performing a firmware upgrade.
Wireless Configuration
Mode
Displays the current operating mode of the access
point.
ESSID
Displays current ESSID (the name used to identify the
access point).
Channel Number
Displays current wireless channel number.
Security
Displays the current wireless security setting.
BSSID
Displays the current BSSID (a unique ID of the access
point, which cannot be modified).
Associated Clients
Displays the number of connected wireless clients.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
