Edimax EW-7416APn v2 User Manual

42
III-5-1. Disable
When you select “Disable”, wireless encryption for the network is disabled.
This means anyone who knows the device’s SSID can connect to it, and is not
recommended.
Enable 802.1x
Authentication
Check this box to enable 802.1x user authentication.
See III-5-2. 802.1x Authentication.
Click “APPLY” to save changes. The following message will appear:
Click “CONTINUE” to save the changes and continue configuring other settings,
or click “APPLY” to restart the system and make the changes take effect.
III-5-2. Enable 802.1x Authentication
If you select “Disable” or “WEP” as your encryption type, you can check the
“Enable 802.1x Authentication” box to enable 802.1x authentication based on
a RADIUS user authentication server.
Use internal
MD5/PEAP RADIUS
Server
Check the box to use an internal MD5/PEAP RADIUS
Server.
Enable 802.1x
Authentication
Enable or disable the use of 802.1x user authentication.
RADIUS Server IP
Address
Enter the IP address of the RADIUS authentication
server here.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
