Edimax EW-7416APn v2 User Manual

56
button is located on the front panel of the
device.
III-10. Upgrade
The access point’s upgrade feature allows you to update
the system firmware to a more recent version. You can
download the latest firmware from the Edimax website.
Selecting “Upgrade” from the menu on the left side will
bring you to the following screen.
Click on the “Choose file” button to open a window and locate the
downloaded firmware file. Confirm your selection and click “APPLY”. A
firmware upgrade may take several minutes. The following message will
appear:
Please wait for the upgrade to complete. When it is complete, you will see the
following message.
Note: Do not turn off or disconnect the
access point during a firmware upgrade, as
this could damage the device.
Note: It is recommended that you use a
wired Ethernet connection to upload the
firmware file.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
