Edimax EW-7416APn v2 User Manual

44
128-bit. Using “128-bit” is safer than “64-bit”, but will
reduce some data transfer performance.
Key Format
Select a key format: ASCII or Hex. The key length will
also be displayed here - ASCII and Hex keys vary in
length according to “Key Length” (above)”.
Default Tx Key
You can set up to four sets of WEP keys, and you can
decide which key is used the default. If you are unsure,
leave the value as the default “Key 1”.
Encryption Key 1 to
4
Enter WEP key here, the number of characters must be
the same as the number displayed in the “Key Format”
field. For “ASCII” key format, you can use any
alphanumerical characters (0-9, a-z, and A-Z). For “Hex”
format, you can use the characters 0-9, a-f, and A-F. You
must enter at least one encryption key here and if you
enter multiple WEP keys, each should be unique.
Enable 802.1x
Authentication
Check this box to enable 802.1x user authentication.
See III-5-2. Enable 802.1x Authentication.
Click “APPLY” to save changes. The following message will appear:
Click “CONTINUE” to save the changes and continue configuring other settings,
or click “APPLY” to restart the system and make the changes take effect.
III-5-4. WPA Pre-Shared Key
WPA pre-shared key is the recommended and most secure encryption type.
WPA Unicast Cipher
Select from WPA (TKIP), WPA2 (AES) or WPA2 Mixed.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
