Edimax EW-7416APn v2 User Manual

34
channel number must be the same as the other access
points you wish to connect to.
Associated Clients
Click the “Show Active Clients” button and a new
window will appear which displays information about
wireless clients connected to this access point. Click the
“Refresh” button in the new window to refresh the list.
MAC address 1-4
Enter the MAC addresses of the wireless access points
you wish to connect to.
Set Security
Click “Set Security” to select an encryption mode for
this wireless link. A new window with security options
will appear.
Click “APPLY” to save changes. The following message will appear:
Click “CONTINUE” to save the changes and continue configuring other settings,
or click “APPLY” to restart the system and make the changes take effect.
III-2-6. Universal Repeater Mode
In universal repeater mode, the access point acts as a wireless extender,
performing both the functions of a client and an access point. It can extend
the Wi-Fi coverage of an access point and eliminate Wi-Fi dead zones.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
