Edimax EW-7416APn v2 User Manual

52
Click “APPLY” to save changes. The following message will appear:
Click “CONTINUE” to save the changes and continue configuring other settings,
or click “APPLY” to restart the system and make the changes take effect.
III-8-2. Management IP
You can modify the IP address of the access point, enabling it to become a part
of your local area network. To do so, input the IP address, subnet mask and
gateway address into the corresponding fields.
Management IP
IP Address
Specify an IP address here. This IP address will be
assigned to your access point, and will replace the
default IP address 192.168.2.1.
Subnet Mask
Input the subnet mask of the new IP address.
Gateway Address
Input the network’s gateway IP address.
DHCP Server
Select “Enabled” if you wish to use the DHCP function
of the access point, as detailed below.
Typically, your ISP will provide you with such information as IP address, subnet
mask and gateway address.
Note: Please write down and remember the
new IP address you assigned to the access
point. If you forget this IP address you may

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
