Edimax EW-7416APn v2 User Manual

45
Suite
AES is safer than TKIP, but not supported by all wireless
clients. Please make sure your wireless client supports
your selection. WPA2(AES) is recommended, or WPA2
Mixed if your client does not support AES.
Pre-shared Key
Format
Select the pre-shared key format from “Passphrase” (8
to 63 alphanumerical characters) or “Hex (64 characters
0 to 9 and a to f.)
Pre-shared Key
Please enter the key according to the key format you
selected above. For security reasons, it’s best to use a
complex, hard-to-guess key.
Note: TKIP only supports up to 54Mbps
transmission data rate.
Click “APPLY” to save changes. The following message will appear:
Click “CONTINUE” to save the changes and continue configuring other settings,
or click “APPLY” to restart the system and make the changes take effect.
III-5-5. WPA Radius
WPA RADIUS is a combination of WPA encryption and RADIUS user
authentication. If you have a RADIUS authentication server, you can
authenticate the identity of every wireless client against a user database.
WPA Unicast Cipher
Suite
Select from WPA (TKIP), WPA2 (AES) or WPA2 Mixed.
AES is safer than TKIP, but not supported by all wireless

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
