Edimax EW-7416APn v2 User Manual

53
not be able to connect to the browser-based
configuration interface in the future.
Note: To reset the IP address back to its
default value of 192.168.2.1, press and hold
the WPS/Reset button on the access point for
10 seconds. Be aware that doing so restores
all settings and passwords back to factory
defaults.
Click “APPLY” to save changes. The following message will appear:
Click “CONTINUE” to save the changes and continue configuring other settings,
or click “APPLY” to restart the system and make the changes take effect.
III-8-3. DHCP Server
The access point can be configured to act as a DHCP server for your network.
By default DHCP is disabled. Enable DHCP by selecting “Enable” in the field
“DHCP Server” of “Management IP” as detailed in the previous section.
DHCP Server
Default Gateway IP
Specify the IP address of the default gateway of your
network here.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
