Edimax EW-7416APn v2 User Manual

82
client.
configuration interface) is “Enabled” or
“Disabled”. If “Disabled” you need to input the
ESSID into your wireless client manually.
b. Try moving closer to the access point
File transfers are slow or
frequently interrupted.
a. Try to move closer to where the wireless access
point is located.
b. Try again later. Your local network may be
experiencing technical difficulties or very high
usage.
c. Change channel number.
I can’t log onto the
browser-based
configuration interface:
incorrect password.
a. Password is case-sensitive. Make sure the “Caps
Lock” light is not illuminated.
b. If you do not know your password, restore the
device to factory settings.
The access point is
extremely hot.
a. It is normal for the access point to heat up
during frequent use. If you can safely place your
hand on the access point, the temperature of
the device is at a normal level.
b. If you smell burning or see smoke coming from
access point or A/C power adapter, then
disconnect the access point and A/C power
adapter immediately, as far as it is safely
possible to do so. Call your dealer of purchase
for help.
IV-4. Glossary
Default Gateway (Access point): Every non-access point IP device needs to configure a
default gateway’s IP address. When the device sends out an IP packet, if the destination is
not on the same network, the device has to send the packet to its default gateway, which
will then send it out towards the destination.
DHCP: Dynamic Host Configuration Protocol. This protocol automatically gives every
computer on your home network an IP address.
DNS Server IP Address: DNS stands for Domain Name System, which allows Internet
servers to have a domain name (such as www.Broadbandaccess point.com) and one or
more IP addresses (such as 192.34.45.8). A DNS server keeps a database of Internet
servers and their respective domain names and IP addresses, so that when a domain
name is requested (as in typing "Broadbandaccess point.com" into your Internet
browser), the user is sent to the proper IP address. The DNS server IP address used by the

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
