Edimax EW-7416APn v2 User Manual

57
Refresh your browser to return to the “Status and Information” homepage of
the browser based configuration device.
III-11. Reset
If the access point malfunctions or is not responding, then
it is recommended that you reset the device. This feature is
useful if the location of the access point is not convenient.
To reset the access point, click “Reset” in the menu on the left side of the
browser based configuration interface and the following screen will be
displayed.
Please click “Apply” to reset the device. A new window will ask you to confirm,
as shown below.
Note: If the access point is still not responding
after a reset, then switch off the device by
disconnecting the power supply and wait for 10
seconds before reconnecting the power.
Note: Resetting the device will not affect the
current settings and configuration.

Edimax EW-7416APn v2 Specifications

General

2.4 GHz	Yes
Modulation	-
Frequency band	2.4 - 2.4835 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	300 Mbit/s
Flash memory	4 MB
Internal memory	16 MB
Processor model	Ralink RT3052
Compatible operating systems	Windows 95/98/ME/2000/XP/Vista
Internal	No
Certification	CE, FCC
Product color	White
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, 802.1x RADIUS, TKIP, WPA, WPA2, WPS
Antennas quantity	2
Antenna gain level (max)	3 dBi
Input current	1 A
AC input voltage	5 V
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Width	127 mm
Height	30 mm
