EDMI ES-10B - Page 35

ES-10B 4 Terminal Single Phase Residential Electricity
Meter - Product Guide
Copyright © 2019 EDMI Europe Ltd. All rights reserved
Version / Status: 1.1
Public
PAGE 35 OF 62
For example:
This indicates that the first message in the Event Log (001) is Event Code 1234.
Pressing OK will display:
This shows that Event 001 occurred at 23:01:15 on 01.01.15. The display will cycle between the
time and date every two seconds.
When in this menu the UI buttons perform the following actions:
Left / Right
Scroll up or down the table. Wrapped.
OK
Cycle between two tables, holding same row position in both at the same time.
Return
Return to parent menu.
13.5.7 Supply
The Supply menu display the supply state as either being Enabled, Disabled (displayed as Disabld
to fit on the screen), or Armed.
For example:
When in this state the UI buttons perform the following actions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
If the supply state is Armed, until a PIN is successfully entered, the screen will show:
Once a valid PIN is entered the screen will cycle between the two following displays:
0
0
1
1
2
3
4
0
0
1
0
1.
0
1.
1
5
0
0
1
2
3:
0
1:
1
5
E
N
A
B
L
E
D
A
R
M
E
D
P
I
N
R
E
Q
