EDMI ES-10B - Page 36

ES-10B 4 Terminal Single Phase Residential Electricity
Meter - Product Guide
Copyright © 2019 EDMI Europe Ltd. All rights reserved
Version / Status: 1.1
Public
PAGE 36 OF 62
Press and hold the OK button for one second to enable the supply.
13.5.8 Join
The Join option enables you to start the ZigBee rejoin process ad-hoc in cases where the trust
centre has to be swapped and the automatic retries are infrequent enough to need to be controlled
manually.
The Find and Join SMHAN operation will result in an Event Log entry with User Interface
Command Code 0x001A
13.5.9 DIAL
The DIAL menu is used for in-service testing, allowing engineers to witness the accumulation of
energy on a smaller scale that is provided on the main screen.
The screen displays the import and export register readings, cycling at 5 second intervals.
For example:
When in this menu the UI buttons perform the following actions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
13.5.10 Version
The Version menu provides information about the:
 Software Version
 Firmware Version
 Configuration Version
13.5.10.1 Software Version
The Softw menu displays the software version and the integrity check version.
For example:
A
R
M
E
D
H
O
L
D
O
K
T
O
E
N
A
B
L
E
I
M
P
R
T
1
2
3
4.
5
6
7
E
X
P
R
T
0.
1
2
3
