EDMI ES-10B - Page 38

ES-10B 4 Terminal Single Phase Residential Electricity
Meter - Product Guide
Copyright © 2019 EDMI Europe Ltd. All rights reserved
Version / Status: 1.1
Public
PAGE 38 OF 62
13.5.11 HAN
The HAN menu options provide, for each device on the Home Area Network, the following
information:
 The EUI64.
 The Received Signal Strength Indicator (RSSI).
 The time and date of the last successful communication from the meter to the selected device.
13.5.11.1 Devices
Each heading in the HAN menu is taken from the Device Log and is identified as one of:
 CHF
 PPMID
 IHD
If there is more than one device of the same type on the HAN, a number will be appended to the
name. For example:
13.5.11.2 EUI64
Displays the EUI64 of the selected device.
For example:
When in this menu, the UI buttons perform the following functions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
13.5.11.3 RSSI
The RSSI menu displays the Received Signal Strength Indicator, which displays the link quality of
received ZigBee packets, in units of dBm. Once received, the value is refreshed every three
seconds.
When you first enter this menu, the screen displays:
P
P
M
I
D
1
E
U
I
6
4
1
2
3
4
5
6
7
