The meter samples the RSSI for three seconds and then displays the signal strength. For example:
When in this menu, the UI buttons perform the following functions:
Left / Right
No effect.
OK
No effect.
Return
Return to parent menu.
13.5.11.4 Comms
The Comms menu displays the time and date last successful communication from the meter to the
selected device.
The display will automatically cycle between time and date every three seconds. You can use the
left/right buttons to manually scroll between the two displays.
For example:
When in this menu, the UI buttons perform the following actions:
Left / Right
Scroll between two screens.
OK
No effect.
Return
Return to parent menu.
13.5.12 LCD
The LCD menu option enables you to test that all LCD pixels are functioning. All LCD segments
should be on for two seconds and then off for two seconds.
When in this menu, the UI buttons perform the following actions:
Left / Right
No effect.
OK
No effect.
