When in this menu the UI buttons perform the following actions:
Left / Right
Scroll up or down the table. Wrapped.
OK
Cycle between two tables, holding same row position in both at the same time.
Return
Return to parent menu.
13.8.3 ALCS
The ALCS menu option tests the ALCS switch by causing it to change states for five minutes and
then returning it to its previous state (e.g. if the switch is closed it will be opened for five minutes
and then close again). When you enter the Test ALCS menu, it will identify the number that has
been assigned to the switch.
For example:
On selection of this menu, the screen displays:
Press and hold the OK button for one second to start the test. The screen will display the state of
the ALCS. For example, if the switch was originally open, the switch would close for five munites
and the screen would display:
After the test has completer (five minutes), the screen will display the following for five seconds:
After which, the screen displays:
This test results in an Event Log entry 0X0013.
When in this menu, the UI buttons perform the following functions:
