EDMI ES-10B - Page 48

ES-10B 4 Terminal Single Phase Residential Electricity
Meter - Product Guide
Copyright © 2019 EDMI Europe Ltd. All rights reserved
Version / Status: 1.1
Public
PAGE 48 OF 62
Left / Right
No effect.
OK
1 second hold initiates the ALCS test.
Return
Return to parent menu.
13.8.4 Leave
To initiate the ZigBee network leave process. The meter shall only send a NWK leave message
(announcement) if it has the active network key. If the meter does not have the active network key
then it shall silently leave the network without sending a NWK leave announcement.
Left / Right
No effect.
OK
Initiates the HAN NWK leave.
Return
Back to Parent menu.
Upon Successful Completion
The message will time out after 10 seconds or if dismissed by pressing the OK button. LCD reverts
to Parent Menu.
L
E
A
V
E
H
O
L
D
O
K
O
P
E
N
L
E
A
V
E
C
O
M
P
L
E
T
E
O
P
E
N
