Voltage
Reference
230V
Specified operating
range
207V – 253V
Extended operating
range
184V – 264.5V
Meter Constant
Active Energy: [imp./kWh]: 1000
Reactive Energy: [imp./Varh]: 1000
Configuration
Records power events on configurable thresholds
Frequency
Reference
50Hz
Current
I
ref
(I
b
) Reference /
Nominal Current
5A
I
st
Starting Current
0.02A
I
min
Minimum Current
0.25A
I
tr
Transitional Current
0.5A
I
max
Maximum Current
100A
Main Relay
Main disconnect relay: 100A
Long term overcurrent: 140A for 2 hours BS 7856:2017
Disconnect Rating: IEC62052-31:2015 UC3 @ 100A, 230VAC
Auxiliary Relay
Auxiliary Load Control Switch(ALCS) (230V, 2A)
Environmental
Insulation Strength
Class II meters (IEC Protection Class)
Measurement CAT
CAT III (Working Voltage 300V / Transient Overvoltage 4000V)
Operating Temperature
Specified Operating: -10ºC to 40ºC
Limit range of operating: -25ºC to 55ºC
Limit range for storage: -25ºC to 55ºC
