ELECTRIC MOTOR:
The temperature sensor
monitors the eld coil tem-
perature, an indication of
>75°C (167°F), the inter-
nal temperature is too hot.
Option 1: Performed by
authorized personnel,
Carefully remove the mo-
tor eld bolt and install the
temp sensor. Install the
bolt and torque to manu-
facturers specications.
Option 2: Use the sup-
plied tape, clean the area
with de-grease agent, dry,
and apply the tape over
the sensor and part of the
wire.
Temp Sensor Mount:
Electric Motor: Two options: 1) Motor eld coil bolt or secure
using the included Aluminized tape. (Both methods shown)
Gas Engine: 10mm bolt (optional water jacket sensor avail-
able, contact your dealer for more info).
Temp Sensor Installation
18
