Data Setting
49
DC Warning:
A warning can be set to alert the operator when batteries are be-
low this setting ashing the Yellow LED. Check with your battery
manufacturer specifications. The following is general guidelines
for LEAD ACID batteries:
12V Battery: Warning 10.5-11.0V (Gas vehicles)
24V Battery: Warning 21V
36V Battery: Warning 31.5V
48V Battery: Warning 42.0V
Setting to 0 disables the alert. (Factory default = 0 no warning)
MODIFY FLASHING DIGITS BY PRESSING THE
LEFT BUTTON.
TO CONFIRM PRESS THE CENTER BUTTON.
EX-RAY will go to the next screen.
CHANGE TO NEXT DIGIT BY PRESSING
RIGHT BUTTON.
