DC Danger
As batteries are depleted below a certain voltage, damage can
occur. DC DANGER Level can be set to alert the operator the
batteries are below this setting ashing the RED LED. Both the
Yellow and Red LED will Flash. Check with your battery manu-
facturer specifications. The following is general guidelines for
LEAD ACID batteries:
12V Battery: Warning 9.75V
24V Battery: Warning 19.5V
36V Battery: Warning 29V
48V Battery: Warning 39V
Setting to 0 disables the alert. (Factory default = 0 no warning)
50
Data Setting
MODIFY FLASHING DIGITS BY PRESSING THE
LEFT BUTTON.
TO CONFIRM PRESS THE CENTER BUTTON.
EX-RAY will go to the next screen.
CHANGE TO NEXT DIGIT BY PRESSING
RIGHT BUTTON.
