EX-RAY Features
Voltage:
The Volt meter shown on SCREEN 1 o& 2
will provide the user with a numeric display
of the actual battery voltage.
For gas powered vehicles, the 12V alterna-
tor, battery, and electrical health can be
monitored.
For electric vehicle, monitoring battery pack
voltage allows the user to monitor when the
battery is depleted.
DESCRIPTION:
For 48V systems: The voltage display
cannot read above 52.6VDC limited by its
design.
If the voltage is above 52.6V, the reading will
change to HI as shown below.
48V battery systems, when fully charged ,will
drop below 52.6VDC in a matter of seconds
under load.
57
