BOLT SENSOR - LIFTED CLUB
CAR or JAKE’S LIFT KIT / HUB
AXLE Mount:
Attach cable ties to the steering arm.
Rotate the steering wheel FULL
LEFT and FULL RIGHT and check
for binding.
Route the cable as described
earlier.
CAUTION: THE CABLE MUST
NOT CONTACT THE
MOVING STEERING KNUCKLE
OR TIRE!
Secure the cable with cable clamps.
Watch for CHAFFING points that
may damage the cable. Always use
TWO cable ties side by side (should
one break in the future).
Mount the wheel and recheck for
rubbing or any damage that may
occur to the cable.
Feed the connector through the
TOP of the steering column. Let
cable hang for now. (as shown in
the Temp Extension Cable Installa-
tion section)
