Appendix A: System addressing
P/N 3102309-EN • REV 001 • ISS 18JUL19 49
Figure 13: Logical addressing for control unit with one node (4-CAB21DL inner door/4-CAB21B backbox shown)
Table 11: Logical addressing for a control unit with one node
Card
Logical address
Operator layer modules on the inner door frame assembly
4
-LCD NNN064(065)
Control
-display modules NNN066 to NNN087
Hardware LRMs on the 3
-CHAS7 chassis
4
-CPU NNN000
Local rail modules
NNN001 to NNN019
000
064
072
080
073
081
001
066
074
082
008
015
006
013
002
067
075
083
009
016
007
014
003
068
076
084
010
017
004
069
077
084
011
018
005
070
078
086
071
079
087
012
019
