Edwards EST4 - Page 61

Appendix A: System addressing
P/N 3102309-EN • REV 001 • ISS 18JUL19 53
Module type
Switch group
Switch address
Indicator address
7 0009 0137
8 0010 0138
9 0011 0139
– – 0140
10 0013 0141
11 0014 0142
12 0015 0143
0144
13 0017 0145
14 0018 0146
15 0019 0147
– – 0148
16 0021 0149
17 0022 0150
18 0023 0151
– – 0152
4
-24L24S 1 to 24 0001 to 0024 0129 to 0152
Figure 16: EST3 control-display LED and switch numbering
Table 15: EST3 operator layer control-display addresses
Module type
Switch group
Switch address
Indicator address
3
-24G, 3-24R, 3-24Y, 3-12RY N/A N/A 0129 to 0152
3-24G, 3-24R
3-24Y, 3-12RY
3-12SG,3-12/SR,
3-12SY
3-12/S1GY, 3-12/S1RY,
3-12/S2Y
3-4/3SGYWR
