Edwards STP-iXL455

STP-iX455/iXL455 Series Instruction Manual
9-26
Operation
9.4.5 ReadModFonct
Function:
Reads the pump operation mode and the errors being detected.
The data of errors being detected reads the same data as that of "ReadFailMess".
Transmission Frame:
PC→SIM
Stx 0 0 1 ? M Etx LRC
SIM→PC
Ack
PC→SIM
Ack
SIM→PC
Stx 0 0 1 Sp M Parameter 1 to 81
*1
Etx LRC
Parameter Item Data format Remarks
1 Pump operation mode
8-bits hexadecimal
coded ASCII
See Table 9.10
2 The number of error
8-bits hexadecimal
coded ASCII
Up to 79 errors
*1
3 ~ 81
*1
Error 1
8-bits hexadecimal
coded ASCII
…
…
*2
Error 79
*1
8-bits hexadecimal
coded ASCII
*1
: The maximum number of errors may differ depending upon the software version of STP
pump. It is recommended that an application is designed as variable-length data.
*2:
Value corresponding to the error is transmitted (see Table 9.9).
The recent error has the largest parameter number. When the number of errors being
detected is under the maximum number, the value of parameter that is larger than the
number of errors being detected is set to 0.
