Edwards T-STATION 85

General
descripon
For the general descripon of the major components used on the T-Staon 85, select the
appropriate instrucon manual reference against each product type.
Diaphragm pump XDD1 A746-02-885
Rotary vane pumps E2M0.7 / E2M1.5 A371-32-880
Turbomolecular pumps nEXT85 B8G0-00-880
Overview
The
T-Staon 85 is a small compact fully automac pumping system which is suitable for a
wide range of vacuum applicaons.
The T-Staon 85 can be supplied with either an XDD1 oil free diaphragm pump or an E2M1.5
rotary vane pump. Both system variants use a nEXT85 turbomolecular pump.
The T-Staon 85 is controlled by an easy to use touch pad control module. A single gauge input
included can be connected to a range of Edwards acve gauges allowing for pressure
measurement and/or control management of the turbomolecular pump.
The compact size of the T-Staon 85 is ideal for use on bench tops or suitable mobile
plaorms. The open system conguraon allows easy maintenance of the main pump
components.
Figure 1
General view of the T-Staon 85
A. Front view (T-Staon with E2M1.5 backing pump opon)
B. Rear view (T-Staon with XDD1 backing pump opon)
1. T-Staon control unit
2. E2M1.5 gas ballast control
3. Backing pump
4. Turbomolecular pump inlet
5. Turbomolecular pump connector
6. Vacuum gauge input
7. T-Staon xing points for bench top
mounng
8. T-Staon liing handles
9. Backing pump mains connector
10. Mains input
D395-94-880A - General descripon
Page 10
