S
ERVICING
THE
E-43A
WI
TH
FURNITURE
119
3
Remov
e the thumbscrew
s that attach th
e E-43A stability brack
et to the
stand.
4
Lift the br
acket and gently pul
l the E-43A away fr
om the table top.
Make sure to pull the
E
-43A out just enough so that the front panel of the E-43A is aligned
with the back edge of the table top
.
Stability bracket
Thumbscrew
s
