Eizo ColorEdge CS2740 User Manual

27
Chapter 4 Advanced Adjustments/Settings
Function Settings Description
Gamma 1.6 to 2.7
sRGB
Adjust the gamma.
The brightness of the monitor varies depending on the input
signal, however, the variation rate is not simply proportional
to the input signal. The control performed to keep the balance
between the input signal and the brightness of the monitor is
called "Gamma correction".
Set the gamma, or select a standard name.
Color Gamut Native
Adobe
®
RGB
sRGB
Set the color reproduction area (color gamut).
"Color Gamut" is the range of colors that can be represented.
Multiple standards are dened.
Note
• When you select "Native", the screen is displayed in the
original color gamut of the LCD panel.
• The method of displaying colors outside the monitor's
displayable range within the dened color gamut can be set.
For more information, see "Gamut Clipping" (page 28).

Eizo ColorEdge CS2740 Specifications

General

Pixel pitch	0.155 x 0.155 mm
Screen shape	Flat
Pixel density	164 ppi
Response time	10 ms
Display diagonal	26.9 \
Adobe RGB coverage	99 %
Display technology	LED
Native aspect ratio	16:9
Maximum refresh rate	- Hz
Viewable size, vertical	2160 mm
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	68.4 cm
Viewable size, horizontal	596.2 mm
Digital vertical frequency	23 - 61 Hz
Digital horizontal frequency	25 - 137 kHz
Display brightness (typical)	350 cd/m²
Certification	CB, CE, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics
Product color	Black
Market positioning	Graphics design
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	168 W
Power consumption (typical)	36 W
Power consumption (PowerSave)	1 W
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 35 °
Cable lock slot type	Kensington
Panel mounting interface	100 x 100 mm
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
USB upstream port type	USB Type-B, USB Type-C
Number of upstream ports	2
USB Power Delivery up to	60 W
USB Type-A downstream ports quantity	4
Number of USB Type-B upstream ports quantity	1
Cables included	AC, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	265 mm
Width (with stand)	638 mm
Height (with stand)	404.1 mm
Weight (with stand)	10300 g
Depth (without stand)	75 mm
Height (without stand)	378.2 mm
Weight (without stand)	6700 g
