Specifications
Item Description
Connections
Power
RS-232 Ports (4-HC4 / 8-HC8)
RS-485 Ports (1-HC4 / 2-HC8)
VIA!NET
ELAN Sense Inputs (2-HC4 / 4-HC8)
IR Outputs (2-HC4 / 3 HC8)
External IR Input
Programming
Relay
Modem
Audio Outputs (1-HC4 / 2-HC8)
Video
Connector Type
HC4 – 12VDC Power Adapter / HC8 - 3-Prong Heavy Duty AC Power Cord
RJ-45 (EIA 561 pinout)
RJ-45
RJ-45
3.5mm Connectors (stereo)
3.5mm Connector (mono)
3.5mm Connector (quad)
RJ-45 (Ethernet Port)
3-position screw terminals
USB
3.5mm Connectors (Stereo)
Component Video
Internal Player Audio Output
Frequency Response
THD+ Noise (@1KHz)
Signal-to-Noise (A Weighted)
20 to 20KHz - +/-/1dB
<0.006%
>102dB
General
Power Consumption
Relay Rating
3.5mm IR Outputs
HC4 – 12V, 2.1 Amps / HC8 - 110-240V ~50-60 Hz - 60W
24V AC/DC, 1 Amp Maximum
12VDC
Video Inputs
Component Video Input
Input Impedance
1V Peak-to-Peak Nominal
75 Ohm
Video Outputs
Component Video Outputs
Output Impedance
Video Gain
1V
Peak-to-Peak Nominal
75 Ohm
Unity
Dimensions
HC4
HC8
8.25” W x 1.6” H x 5.125” D (209.55mm W x 40.64mm H x 130.17mm D)
12.5” W x 1.75” H x 9.375” D (317.5mm W x 44.45mm H x 238.13mm D)
Weight
HC4
HC8
1.1 lbs (.5 kg)
3.1 lbs (1.41 kg)
