elco Firebird FB 2 K LN - Structure of the Combustion Head

GENERAL
12/64
EN
2.4.2 Structure of the combustion head
1
5 64
3
2 7 6
1 Combustion head
2 Diffuser
3 Electrode group
4 Diffuser fixing screw
5 Electrode group fixing screw
6 Combustion head fixing screw
7 Nozzle
Fig. 4
