elco Firebird FB 2 K LN User Manual

MAINTENANCE
44/64
EN
6.3 Removing the burner
DANGER
Danger of death caused by live components!
Before carrying out any operations on the burner, operate the main power switch for the system
to cut off the power supply.
To remove the burner from the boiler, proceed as follows:
– close the fuel taps upstream of the burner
– loosen the two screws (1) and then slide out the burner cover (2) taking care not to damage it.
2
B
1
1
A
Fig. 38
– detach the electrical connector (3) from the boiler
3
Fig. 39
