MAINTENANCE
50/64
EN
– check the distance between the diffuser (1) and the nozzle (2) as shown in the gure.
12
Fig. 47
– after having adjusted the position of the diffuser tighten the screw (8).
– ret the combustion head.
8
1X
Fig. 48
