23
SPINDLE SELECTION TABLES
R
6.3 LCP Spindle
Volume of sample container = 18 ml (0.61 oz)
Shear Rate (S.R.) = 1.224 x rpm
Table 5: Spindle type LCP
a
a. Type LCP spindle is supplied as part of the Adaptor for Low Viscosity Materials kit of parts; See “Spare parts
and accessories” on page 28.
Spindle
speed (rpm)
Maximum
b
measurable
viscosity (mPa•s)
b. The minimum recommended reading is 15% of the full scale value.
RV1-L / RV2-L RV1-R / RV2-R
0.3 2000 21 333
0.5 1200 12 800
0.6 1000 10 666
1 600 6400
1.5 400 4266
2 300 3200
2.5 240 2560
3 200 2133
4 150 1600
5 120 1280
6 100 1066
10 60 640
12 50 533
20 30 320
30 20 213
50 12 128
60 10 106
100 6 64
200 3 32
Resolution 0.01 mPa•s 0.16 mPa•s
