Elcometer 2300 Series User Manual

24
SPINDLE SELECTION TABLES
R
6.4 P series spindles
Table 6: P series spindles for RV1-L and RV2-L Viscometers
a
a. Type P series spindles are the optional spindles for use with the Adaptor for Helical Movement - See “Spare
parts and accessories” on page 28.
Spindle
speed
(rpm)
Maximum
b
measurable viscosity (mPa•s)
b. The minimum recommended reading is 15% of the full scale value.
PA PB PC PD PE PF
0.3 62 400 124 800 312 000 624 000 1 560 000 3 120 000
0.5 37 440 74 880 187 200 374 400 936 000 1 872 000
0.6 31 200 62 400 156 000 312 000 780 000 1 000 000
1 18 720 37 440 93 600 187 200 468 000 936 000
1.5 12 480 24 960 62 400 124 800 312 000 624 000
2 9360 18 720 46 800 93 600 234 000 468 000
2.5 7488 14 976 37 440 74 880 187 200 374 400
3 6240 12 480 31 200 62 400 156 000 312 000
4 4680 9360 23 400 46 800 117 000 234 000
5 3744 7488 18 720 37 440 93 600 187 200
6 3120 6240 15 600 31 200 78 000 156 000
10 1872 3744 9360 18 720 46 800 93 600
12 1560 3120 7800 15 600 39 000 78 000
Resolution 1 mPa•s 1 mPa•s 2 mPa•s 4 mPa•s 8 mPa•s 16 mPa•s
Table 7: P series spindles for RV1-R and RV2-R Viscometers
a
a. Type P series spindles are the optional spindles for use with the Adaptor for Helical Movement - See “Spare
parts and accessories” on page 28.
Spindle
speed
(rpm)
Maximum
b
measurable viscosity (mPa•s)
b. The minimum recommended reading is 15% of the full scale value.
PA PB PC PD PE PF
0.3 666 600 1 300 000 3 300 000 6 600 000 16 600 000 33 300 000
0.5 400 000 800 000 2 000 000 4 000 000 10 000 000 20 000 000
0.6 333 300 666 600 1 600 000 3 300 000 8 300 000 16 600 000
1 200 000 400 000 1 000 000 2 000 000 5 000 000 10 000 000
1.5 133 300 266 600 666 600 1 300 000 3 300 000 6 600 000
2 100 000 200 000 500 000 1 000 000 2 500 000 5 000 000
2.5 80 000 160 000 400 000 800 000 2 000 000 4 000 000
3 66 600 133 300 333 300 666 600 1 600 000 3 300 000
4 50 000 100 000 250 000 500 000 1 250 000 2 500 000
5 40 000 80 000 200 000 400 000 1 000 000 2 000 000
6 33 300 66 600 166 600 333 300 833 300 1 600 000
10 20 000 40 000 100 000 200 000 500 000 1 000 000
12 16 600 33 300 83 300 166 600 416 600 833 200
Resolution 5 mPa•s 10 mPa•s 25 mPa•s 50 mPa•s 125 mPa•s 250 mPa•s
2300_TMA_0377_00_01.book Page 24 Thursday, March 29, 2007 1:32 PM
