12
2.9 Interfaces
The gauge is fitted with an infrared interface (Figure 7)
which allows information to be sent to a suitable printer.
Figure 7. Infrared and RS232 interfaces
The RS232 5-pin connector next to the infrared interface
is used with an optional PC connection cable to connect
the gauge to a PC. This enables personalised screens to
be downloaded to the gauge (see “Personalised
welcome screen” on page 38).
Infrared interface
RS232 5-pin
connector
Op_456_2_English.book Page 12 Friday, February 17, 2006 3:35 PM
