17
3 Connecting the driver/controller
This chapter tells you how to connect the power supply, network and LED leads to the driver/
controller, and lists information regarding wire sizes.
3.1 Required wire sizes
The following diagram lists the required wire sizes for the various connectors and the length of
insulation material you need to strip away from the leads.
3.1.1 LINEARdrive 180
The diameter of the wires including insulation material should be the same
for all wires on the same side. The diameter of the wires including insulation
material should be between 0.99mm and 3.12mm.
Connector
Wire core
diameter in mm
AWG
Insulation material to be
stripped away in mm
VDC 0.14 - 0.5 26 - 20 11
EXT in 0.5 - 1.5 20 - 16 9
DMX in 0.5 - 1.5 20 - 16 9
LedSync thru 0.5 - 1.5 20 - 16 9
LED (Group x) 0.14 - 1 26 - 18 10
