eldoLED LINEARdrive User Manual

31
3-3L
3-3L: Three DMX channels are used for LED groups 1, 2 and 3. Group 4 is disabled.
INT (intensity) lets you set the intensity of the light output of each channel: 255 is full
on, 0 is off.
Figure 4.6: COLR settings for 3-3L
4-4L
4-4L: one DMX channel is used per LED group. INT (intensity) lets you set the intensity
of the light output of each channel: 255 is full on, 0 is off.
Figure 4.7: COLR settings for 4-4L
M
INT 1
M
Group 1 intensity
Group 2 intensity
INT 2
M
M
+
-
/
Group 3 intensity
0...255
INT 3
display off
+
-
/
0...255
+
-
/
0...255
M
INT 1
M
Group 1 intensity
Group 2 intensity
INT 2
M
M
+
-
/
Group 3 intensity
0...255
INT 3
M
+
-
/
Group 4 intensity
0...255
INT 4
display off
+
-
/
0...255
+
-
/
0...255
