18
3.1.2 LINEARdrive 720
3.2 Removing the strain reliefs
Strain reliefs prevent leads from being pulled out by accident. Before you can connect any
leads, you need to remove the strain reliefs.
To remove the strain reliefs:
1. Remove the cover as described in 2.2 “Removing the cover”.
2. Use a phillips crosshead screwdriver to unscrew the screws that fasten the strain re-
liefs to the base unit.
3. Take the strain reliefs out.
Connector
Wire core
diameter in mm
AWG
Insulation material to be
stripped away in mm
VDC 0.14 - 0.5 26 - 20 11
EXT in 0.14 - 0.5 24 - 20 9
DALI in 0.14 - 0.5 24 - 20 9
DALI out 0.14 - 0.5 24 - 20 9
DMX in 0.14 - 0.5 24 - 20 9
LedSync out 0.14 - 0.5 24 - 20 9
LED (Group x) 0.14 - 1 26 - 18 10
