Installation Information
2-9
Connecting Drain and Electrical
1. Snap one end of the drain hose hanger (shipped
in washer drum) onto the drain hose. Continue
wrapping it around the hanger and snap it in place.
2. Place the hook end of the drain hose in the drain
opening. Secure the drain hose with the cable
tie (provided in the enclosure package) to the
standpipe, inlet hose, laundry tub, etc. so the hose
does not pull out from the force of the water.
3. Plug the power cord into a grounded outlet.
4. Turn on the power at a circuit breaker/fuse box.
5. Carefully slide the washer to its final position.
Recheck for level and rock corners for stability.
Remove and discard door tape.
Figure 2-7b. Drain Hose Installation
A wiring diagram and technical data sheet are
located under the washer top panel, on top of the
detergent dispenser housing.
