Installation Information
2-21
Removing Stacked Dryer
1. Disconnect dryer from electrical and gas connections
and exhaust venting. On models with Steam Option,
disconnect water supply to dryer.
2. Disconnect washer from electrical source.
3. With #2 square bit screwdriver, remove two front
bracket screws and save for reinstallation.
(See Figure 2-48)
4. Slide the dryer approximately ¼” to the left to
disengage dryer from rear brackets.
5. Support the front of the dryer, clearing the front
bracket, while sliding the dryer forward. Have two or
more people lift the dryer off the washer and gently
place it on the floor.
Figure 2-48.
If laundry appliances must be moved, front and
rear mounting brackets may remain attached to
the washer top until the dryer is restacked. To
permanently unstack the units and remove the
front bracket, use a 24” piece of monofilament
(fishing) line to carefully saw back and forth under
the adhesive strip. Remove residue with a general
adhesive remover.
